产品代号	产品型号	运量 t/h	运距 m	带宽 mm	带速 m/s	倾角（⁰）	电机动率 kw	传动滚筒直径mm	托辊直径 mm	机头外形尺寸（宽×高）（mm）	整机重量 t
上运固定带式输送机
L×78	STJ650/75S	200	315	650	1.6	16.5	75	500	89		31.09
L×119	DTL80/20/250S	200	900	800	2	17	250	1000	89		83.19
L×325	DTL80/30/2×250S	300	1000	800	2.5	17-12	2×250	1250	108		113.87
L×62	STJ800/160S	350	850	800	2	6.5	160	630	108		93.5
L×29	DP440/800S	400	400	800	2	12.5	90	630	108	2451×1697	44.34
L×030	DTL100/30/2×160S	300	1000	1000	2.5	8	2×160	800	108
L×210	DTL100/32/2×220	320	1030	1000	2	16	2×220	1000	133		200.91
L×71	STJ1000/2×125S	350	500	1000	2	11.5	2×125	800	108
L×311	DTL100/40/2×200S	400	1260	1000	2	14	2×200	1000	133		139.35
L×011	DTL100/45/280	450	468	1000	2	5-16	280	1250	108		103.14
L×819	DTL100/50/2×355S	500	1100	1000	2.5	16.5	2×355	1400	108		250.99
L×318	DTL100/60/200	600	1600	1000	2	14	200	630	108	3273×1695	95.91
L×129	DTL100/63/2×200	630	1000	1000	2	8	2×220	1000	133		124.32
L×122	DTL100/70/2×160S	700	300	1000	2.5	16	2×160	800	108		57.99
L×28	STJ1000/2×220S	750	400	1000	2.5	14	2×220	1280	108		77.61
L×34	STJ1000/160S(A)	800	700	1000	2.5	3	160	630	108	2279×1665	65.56
L×323	DTL120/70/2×220S	700	490	1200	2	14.5	2×220	1000	108
L×54	L×STJ1200/2×160S	800	360	1200	2.5	15	2×160	800	103	3064×1956	67.2
L×70	STJ1000/2×200S	950	690	1000	3.15	`8	2×200	800	133	3691×1976	99.91
L×838	DTL100/100/3×250S	1000	1500	1000	3.15	0-12	3×250	1030	133		277.50
L×112	DTL120/50/2×160	500	400	1200	2.5	16	160	500	108	2875×1470	49.97
L×202	DTL120/100/2×250	1000	1498	1200	2.5	14	2×250	1250	133		227.18
L×124	DTL120/120/3×315	1200	1650	1200	2.5	15	3×315	1250	159		148.97
L×204	DTL120/150/3×200	1500	1500	1200	3.15	14	3×200	800	133	3456×2000	184.55
L×317	DTL120/180/2×250	1800	955	1200	3.5	6	2×250	1250	133		164.01
L×921	706	1100	151.37	1400	2.5	15	220	800	159		45.28
L×824	DTL140/120/90	1200	85.54	1400	3.15	0-3	90	800	159		37.67
L×840	DTL140/204/400S	2040	182	1400	3.8	17.8	400	1250	159		74.94
L×821	DTL160/250/280	2500	77.28	1600	3.15	15.5	280	1000	159		38.00
L×101	DTL180/300/2×450	3000	348.3	1800	3.15	0-11	2×450	1036	159		131.5

LXX	SPL-800S	350	300	800	1.63	-8	30	450	108	2100×1350	25
L×52	STJ800/90	400	700	800	2	-15	90	630	108	2566×1697	67.63
L×65	STJ1000/90	400	834	1000	2	-6.5	90	630	108		90.1
L×131	DTL100/45/90	450	640	1000	2	-8	90	630	108		73.77
L×94	STJ1000/2×125	500	1470	1000	2	-3	2×125	630	108	2662×1665	119.65
L×22	DP350/1000S	530	300	1000	2	-10	75	630	108		57.02
L×27	SPJ1000/75	600	120	1000	1.6	-14	75	630	108		22.07
L×236	DTL100/63/200	630	850	1000	2	-16	200	1000	108		141.59
L×04	DTL280/1200S	800	200	1200	2	-10	75	630	108	3030×1700	32.19

L×927	DTL65/2/7.5	20	73.65	650	0.8		7.5	500	89		5.64
L×224	DTL65/5/40	50	309	650	2		40	500	89	1919×1460	21.38
L×308	DTL65/6/22	60	300	650	1.6		22	450	89	1900×1040	14.95
L×931	STD650/22	150	400	650	1.6		22	450	89		13.37
L×208	DTL65/20/22	200	190	650	1.6		22	450	89		10.82
L×136	DTL65/23.5/15	234	68.55	650	2		15	500	89		1.93
L×328	DTK80/18/17	180	60	800	1.6		17	450	89		6.29
L×106	STJ80/20/2×55	200	280	800	2.0		55	500	89		22.87
L×07	SPJ-800	300	300	800	1.63		30＋17	450	108	2030×1665	22.38
L×29	SPJ-800滚筒包胶	350	300	800	1.63		17＋30	450	108	3273×1350	25.00
L×07	DSP1040	400	1800	800	2		90	630	108	2451×1697	58.70
L×913	DTL80/50/22	500	120.33	800	2		22	630	89		13.23
L×127	DTL100/30/125	300	480	1000	2		125	630	108		38.63
L×135	DTL100/50/2×250	500	1000	1000	2.5		2×250	630	108	2540×1665	58.49
L×033	DT100/63/2×90	630	1500	1000	2.5		2×90	630	108	2589×1665	75.09
L×33	STJ1000/3×160	800	1100	1000	2.5		3×160	630	108
L×108	DTL100/100/2×160	1000	750	1000	3.15		2×160	800	133	2655×1950	66.47
L×245	DTL120/80/2×160	800	1000	1200	1.6		2×160	630	108	3307×2150	101.76
L×320	DTL120/90/2×220	900	650	1200	2.5		2×200	830	133		79.62
L×121	DTL120/100/75	1000	200	1200	2.5		75	800	108	2750×1950	32.41
L×306	DTL120/120/2×500	1200	1900	1200	3.15		2×500
L×027	DTL120/135/3×160	1350	2300	1200	2.5		3×160	1000	133	9688×2720	165.61
L×225	DTL120/180/200	1800	500	1200	3.5		×200	800	133	3110×1950	124.30
L×843	DTL120/200/G4×250	2000	2810	1200	3.5		4×250	830	159		494.11
L×920	DTL140/110/132	1100	148.78	1400	3.5		132	800	159		38.51
L×841	DTL140/120/280	1200	60.2	1400	2		280	800	108		17.36
L×823	DTL160/250/55	2500	35.6	1600	3.15		55	1000	159		27.85
